| Brand | Samsung |
| Model | SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T |
| Released | 2022 Aug 26 |
| Announced | 2022 Aug 10 |
| Hardware Designer | Samsung Electronics |
| Manufacturer | Samsung Electronics |
| Codename | Samsung Q4 |
| OEM ID | F936UZEAXAU |
| General Extras | Haptic touch feedback , Active stylus , Foldable screen |
| Device Category | Smartphone |
| Width | 67.1 mm |
| Height | 155.1 mm |
| Depth | 15.8 mm |
| Dimensions | 2.64×6.11×0.62 inches |
| Mass | 263 g |
| Platform | Android |
| Operating System | Google Android 12 (S) |
| Software Extras | Voice Command , Business card recognition , Navigation software , Augmented Reality (AR) , Virtual Reality (VR) support , Intelligent personal assistant , Voice Recognition , Face Recognition |
| CPU Clock | 3190 MHz |
| CPU | Qualcomm Snapdragon 8+ Gen 1 5G SM8475 (Palima), 2022, 64 bit, octa-core, 6144 Kbyte L3, 4 nm, Qualcomm Adreno 730 GPU |
| RAM Type | LPDDR5 SDRAM |
| RAM Capacity (converted) | 12 GiB RAM |
| Non-volatile Memory Interface | UFS 3.1 |
| Non-volatile Memory Capacity (converted) | 256 GB ROM |
| Display Diagonal | 157.3 mm |
| Resolution | 904×2316 |
| Horizontal Full Bezel Width | 9.9 mm |
| Display Area Utilization | 80.5% |
| Pixel Density | 401 PPI |
| Display Type | AM-OLED display |
| Display Subtype | Dynamic AM-OLED |
| Number of Display Scales | 16.8M |
| Display Refresh Rate | 120 Hz |
| Scratch Resistant Screen | Gorilla Glass Victus+ |
| Secondary Display Diagonal: | 192.1 mm |
| Secondary Display Resolution | 1812×2176 |
| Secondary Display Pixel Density (dot pitch): | 374 PPI |
| Secondary Display Type: | AM-OLED 2nd display |
| Secondary Number of Display Colors/Scales: | 16.8M |
| Secondary Display Refresh Rate | 120 Hz |
| Graphical Controller | Qualcomm Adreno 730 |
| GPU Clock: | 900 MHz |
| A/V Out | DisplayPort |
| Microphone(s) | stereo |
| Loudspeaker(s): | stereo |
| Audio Output: | USB Type-C |
| Supported Cellular Bands | GSM850 , GSM900 , GSM1800 , GSM1900 , UMTS2100 (B1) , UMTS1900 (B2) , UMTS1700/2100 (B4) , UMTS850 (B5) , UMTS900 (B8) , LTE2100 (B1) , LTE1900 (B2) , LTE1800 (B3) , LTE1700/2100 (B4) , LTE850 (B5) , LTE2600 (B7) , LTE900 (B8) , LTE700 (B12) , LTE700 (B13) , LTE700 (B14) , LTE800 (B18) , LTE800 (B19) , LTE800 (B20) , LTE1900 (B25) , LTE850 (B26) , LTE700 (B28) , TD-LTE2600 (B38) , TD-LTE1900 (B39) , TD-LTE2300 (B40) , TD-LTE5900 (B46) , TD-LTE3600 (B48) , LTE1700/2100 (B66) , LTE600 (B71) , TD-NR2500 (N41) , NR1700/2100 (N66) , NR600 (N71) , TD-NR39G (N260) , TD-NR28G (N261) bands |
| Supported Cellular Data Links | GPRS , GPRS C12 , EDGE , EDGE MSC12 , UMTS , HSUPA , HSUPA 5.8 , HSDPA , HSPA+ 21.1 , DC-HSDPA 42.2 , LTE , LTE 100/50 , LTE 150/50 , LTE 300/50 , LTE 300/75 , LTE 300/100 , LTE 400/150 , LTE 450/50 , LTE 450/100 , LTE 600/50 , LTE 600/100 , LTE 1000/100 , LTE 1200/200 , LTE 2000/300 , NR 1500 , NR 2600 , NR 3700 , NR 4600 data links |
| SIM Card Slot | e-SIM , Nano-SIM (4FF) |
| Complementary Phone Services | Voice transmission , Voice speaker , Vibrate , Speakerphone , ANC , HD Voice , VoLTE , ViLTE |
| SAR (head) | 0.790 W/kg |
| SAR (body) | 0.630 W/kg |
| SAR (hotspot) | 0.840 W/kg |
| Sec. Supported Cellular Networks: | No |
| Touchscreen Type | Capacitive multi-touch screen |
| Expansion Interfaces | No |
| USB | USB 3.0 / 3.1 Gen 1 / 3.2 Gen 1×1 |
| USB Services | USB charging , USB fast charging , USB Host , USB OTG 1.3 , USB OTG 2.0 , USB PD , USB PD 2.0 , USB PD 3.0 |
| USB Connector | USB C reversible |
| Max. Charging Power | 25.0 W |
| Bluetooth | Bluetooth 5.2 |
| Wireless LAN | 802.11a , 802.11b , 802.11i , 802.11g , 802.11n , 802.11r , 802.11ac , 802.11ax |
| Wireless Services | DLNA , Miracast , Wi-Fi Direct , Wi-Fi Tethering , Wi-Fi Calling |
| NFC | NFC A , NFC B |
| FM Radio Receiver | No |
| Complementary Satellite Services | Simultaneous GPS , A-GPS , Dual-frequency GPS , Geotagging , QuickGPS , QZSS |
| Supported GLONASS protocol(s) | L1OF |
| Supported Galileo service(s) | E1 |
| Supported BeiDou system (BDS) | B1I BeiDou receiver |
| Camera Placement | Rear |
| Camera Image Sensor | BSI CMOS |
| Image Sensor Pixel Size | 1.00 micrometer |
| Number of effective pixels | 50.1 MP camera |
| Aperture (W) | f/1.80 |
| Zoom | 2.9 x optical zoom |
| Focus | PD AF |
| Min. Equiv. Focal Length | 23 mm |
| Video Recording | 7680×4320 pixel |
| Flash | single LED |
| Camera Extra Functions | EIS (video) , OIS , Pixel unification , HDR photo , HDR video , Red-eye reduction , Slow motion video , Burst mode , Refocus , Touch focus , Macro mode , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Face retouch (video) , Intelligent scene detection |
| Aux. Camera Image Sensor | BSI CMOS |
| Aux. Cam. Image Sensor Pixel Size | 1.12 micrometer |
| Aux. Camera Number of Pixels | 12.0 MP aux. cam |
| Aux. Camera Aperture (W) | f/2.20 |
| Aux. Cam. Min. Equiv. Focal Length | 12 mm |
| Aux. Camera Extra Functions | HDR photo , HDR video , Burst mode , Face detection , Face tagging , Smile detection , Face retouch , Intelligent scene detection |
| Aux. 2 Camera Image Sensor | BSI CMOS |
| Aux. 2 Camera Number of Pixels | 10.0 MP aux. 2 cam |
| Aux. 2 Camera Aperture (W) | f/2.40 |
| Aux. 2 Cam. Min. Equiv. Focal Length | 66 mm |
| Aux. 3 Camera Image Sensor | No |
| Aux. 4 Camera Image Sensor | No |
| Secondary Camera Placement | Front |
| Secondary Camera Sensor | BSI CMOS |
| Secondary Camera Number of pixels | 10.0 MP sec. cam |
| Secondary Aperture (W) | f/2.20 |
| Secondary Video Recording | 3840×2160 pixel |
| Secondary Camera Extra Functions | EIS , EIS (video) , HDR photo , HDR video , Slow motion video , Burst mode , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Face retouch (video) , Intelligent scene detection |
| Sec. Aux. Cam. Image Sensor | BSI CMOS |
| Sec. Aux. Camera Number of Pixels | 4.0 MP sec. aux. camera |
| Built-in compass | 3D compass |
| Built-in accelerometer | 3D accelerometer |
| Built-in gyroscope | 3D gyro |
| Additional sensors | Barometer , FP sensor , Hall , L sensor , P sensor |
| Protection from solid materials | Yes |
| Protection from liquids | 8 Protected against immersion beyond 1m of depth |
| Immersion into liquids (depth limit) | 150 cm |
| Immersion into liquids time limit | 30 min |
| Battery | Li-ion polymer (LiPo) |
| Battery Cells in Parallel | Yes |
| Nominal Battery Voltage | 3.88 Volts |
| Nominal Battery Capacity | 4400 mAh battery |
| Nominal Battery Energy | 17.07 Wh |
| Estimated Battery Life | 16.0 hours |
| Talk Time: | 37.0 hours |
| Wireless Charging | PMA , Qi |
| Max. Wireless Charging Power | 15.0 W |
| Market Countries | USA |
| Market Regions | North America |
| Mobile Operator | T-Mobile USA |
Specifications data description of this 📱Samsung SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T📱
Samsung SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T Specifications
=================================================================================
Introduction
————
Welcome to our blog post about the Samsung SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T. This device is a high-end smartphone that offers a range of impressive features. In this post, we will take a closer look at the device’s specifications and provide an overview of its design, lineup, and features.
Lineup
——
The Samsung SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T is a part of Samsung’s flagship lineup of smartphones. It is a premium device that offers features such as a foldable display, 5G connectivity, and a powerful chipset. The device is available in two storage variants – 256GB and 512GB, and comes in a range of colors including black, silver, and gold.
Design
——
The Samsung SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T has a unique design that sets it apart from other smartphones in the market. The device features a foldable display that can be opened and closed like a book. This design allows the device to be used as both a phone and a tablet, providing users with versatility and convenience.
Specifications
————-
Let’s take a closer look at the specifications of the Samsung SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T:
🌐NETWORK
———
* 5G connectivity
* UW TD-LTE US
* Dual SIM
📅LAUNCH
——–
* Q3 2022 (expected)
🏋️BODY
——
* Foldable design
* 158.2 x 67.1 x 15.9 mm (unfolded)
* 158.2 x 128.2 x 6.4 mm (folded)
* 279g weight
🌈 DISPLAY
———
* 7.6 inches (unfolded)
* 4.6 inches (folded)
* Dynamic AMOLED 2X
* HDR10+
* 120Hz refresh rate
* 1768 x 2208 pixels resolution (unfolded)
* 832 x 1960 pixels resolution (folded)
🤖 OS 🛠️
——-
* Android 12
* One UI 4.0
🚀 Chipset 🔧
————
* Qualcomm Snapdragon 8 Gen 1
* Octa-core (1×3.0 GHz Cortex-X2 & 3×2.5 GHz Cortex-A710 & 4×1.8 GHz Cortex-A510)
* Adreno 730 GPU
💪 CPU 🖥️
——–
* Octa-core (1×3.0 GHz Cortex-X2 & 3×2.5 GHz Cortex-A710 & 4×1.8 GHz Cortex-A510)
🎮 GPU 💻
——–
* Adreno 730
🧠 MEMORY 🗂️
————
* 12GB RAM
* 256GB / 512GB internal storage
📷 CAMERA 🎥
———–
* Triple camera setup
* 12MP primary camera
* 12MP ultra-wide camera
* 12MP telephoto camera
* 4MP under-display selfie camera (unfolded)
* 10MP selfie camera (folded)
🔈 SOUND 🎵
———-
* Stereo speakers
* Dolby Atmos
* 32-bit/384kHz audio sampling
📡 COMMS 📶
———-
* Wi-Fi 802.11 a/b/g/n/ac/6e
* Bluetooth 5.2
* NFC
* GPS
💡 FEATURES 🎁
————-
* Fingerprint sensor
* Face recognition
* IPX8 water resistance
* Samsung DeX
* Bixby
🔋 BATTERY🔌
———-
* 4400mAh battery
* Fast charging
* Wireless charging
Conclusion
———-
The Samsung SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T is a powerful and versatile smartphone that offers a range of impressive features. We particularly like the device’s foldable design, which allows it to be used as both a phone and a tablet. The device also offers a powerful chipset, a high-resolution display, and a range of connectivity options. If you’re in the market for a high-end smartphone, the Samsung SM-F936U Galaxy Z Fold4 5G UW TD-LTE US 256GB / SM-F936T is definitely worth considering.
