| Brand | Motorola |
| Model | RAZR 40s 5G 2023 Standard Edition TD-LTE JP 256GB A303MO XT2323-7 |
| Released | 2023 Dec 8 |
| Announced | 2023 Sep 25 |
| Hardware Designer | Lenovo |
| Manufacturer | Lenovo |
| Codename | Motorola Lynkco |
| General Extras | Haptic touch feedback , Tactile touch feedback , Foldable screen |
| Device Category | Smartphone |
| Width | 73.95 mm |
| Height | 170.82 mm |
| Depth | 7.35 mm |
| Dimensions | 2.91×6.73×0.29 inches |
| Mass | 188.6 g |
| Platform | Android |
| Operating System | Google Android 13 (Tiramisu) |
| Software Extras | Voice Command , Navigation software , Intelligent personal assistant , Face Recognition |
| CPU Clock | 2400 MHz |
| CPU | Qualcomm Snapdragon 7 Gen 1 5G SM7450-AB, 2022, 64 bit, octa-core, 3072 Kbyte L2, 4 nm, Qualcomm Adreno 644 GPU |
| RAM Type | LPDDR4x SDRAM |
| RAM Capacity (converted) | 8 GiB RAM |
| Non-volatile Memory Interface | UFS 2.2 |
| Non-volatile Memory Capacity (converted) | 256 GB ROM |
| Display Hole | 1-hole |
| Display Diagonal | 175.26 mm |
| Resolution | 1080×2640 |
| Horizontal Full Bezel Width | 7.59 mm |
| Display Area Utilization | 85.2% |
| Pixel Density | 413 PPI |
| Display Type | AM-OLED display |
| Display Subtype | Foldable AMOLED |
| Number of Display Scales | 1073.7M |
| Display Refresh Rate | 144 Hz |
| Scratch Resistant Screen | Yes |
| Secondary Display Diagonal: | 37.33 mm |
| Secondary Display Resolution | 368×194 |
| Secondary Display Pixel Density (dot pitch): | 283 PPI |
| Secondary Display Type: | AM-OLED 2nd display |
| Secondary Number of Display Colors/Scales: | 16.8M |
| Scratch Resistant Sec. Screen: | Gorilla Glass Victus |
| Secondary Display Refresh Rate | 60 Hz |
| Graphical Controller | Qualcomm Adreno 644 |
| A/V Out | No |
| Microphone(s) | 3 |
| Loudspeaker(s): | stereo |
| Audio Output: | USB Type-C |
| Supported Cellular Bands | GSM850 , GSM900 , GSM1800 , GSM1900 , UMTS2100 (B1) , UMTS1900 (B2) , UMTS1700/2100 (B4) , UMTS900 (B8) , LTE2100 (B1) , LTE1900 (B2) , LTE1800 (B3) , LTE1700/2100 (B4) , LTE850 (B5) , LTE2600 (B7) , LTE900 (B8) , LTE1500 (B11) , LTE700 (B12) , LTE700 (B17) , LTE800 (B18) , LTE800 (B19) , LTE1900 (B25) , LTE850 (B26) , LTE700 (B28) , TD-LTE2600 (B38) , TD-LTE1900 (B39) , TD-LTE2300 (B40) , TD-LTE2500 (B41) , TD-LTE3500 (B42) , NR2100 (N1) , NR1800 (N3) , NR900 (N8) , NR700 (N28) , TD-NR2500 (N41) , TD-NR3700 (N77) , TD-NR3500 (N78) bands |
| Supported Cellular Data Links | GPRS , GPRS C12 , EDGE , EDGE MSC12 , UMTS , HSUPA , HSUPA 5.8 , HSDPA , HSPA+ 21.1 , HSPA+ 42.2 , DC-HSDPA 42.2 , LTE , LTE 100/50 , LTE 150/50 , LTE 225/50 , LTE 300/50 , LTE 300/75 , LTE 300/100 , LTE 450/50 , LTE 450/100 , LTE 600/50 , LTE 600/100 , LTE 750/225 , NR 1500 , NR 2600 data links |
| SIM Card Slot | e-SIM , Nano-SIM (4FF) |
| Complementary Phone Services | Voice transmission , Voice speaker , Vibrate , Speakerphone , ANC , HD Voice , VoLTE |
| SAR (head) | 0.990 W/kg |
| SAR (body) | 0.840 W/kg |
| Sec. Supported Cellular Networks: | No |
| Sec. SIM Card Slot | Nano-SIM (4FF) |
| Touchscreen Type | Capacitive multi-touch screen |
| Expansion Interfaces | No |
| USB | USB 2.0 |
| USB Services | USB charging , USB fast charging , USB Host , USB OTG 1.3 , USB PD , USB PD 2.0 , USB PD 3.0 |
| USB Connector | USB C reversible |
| Max. Charging Power | 33.0 W |
| Bluetooth | Bluetooth 5.3 |
| Wireless LAN | 802.11a , 802.11b , 802.11g , 802.11n , 802.11ac , 802.11ax |
| Wireless Services | Miracast , Wi-Fi Direct , Wi-Fi Tethering , Wi-Fi Calling |
| NFC | NFC A , NFC B , FeliCa |
| FM Radio Receiver | No |
| Complementary Satellite Services | Simultaneous GPS , A-GPS , Dual-frequency GPS , Geotagging , QuickGPS , QZSS |
| Supported GLONASS protocol(s) | L1OF |
| Supported Galileo service(s) | E1 |
| Supported BeiDou system (BDS) | B1I BeiDou receiver |
| Camera Placement | Rear |
| Camera Image Sensor | BSI CMOS |
| Image Sensor Pixel Size | 0.70 micrometer |
| Number of effective pixels | 63.7 MP camera |
| Aperture (W) | f/1.70 |
| Zoom | 1.0 x optical zoom |
| Focus | PD AF , Laser AF |
| Video Recording | 3840×2160 pixel |
| Flash | single LED |
| Camera Extra Functions | EIS (video) , OIS , HDR photo , HDR video , Red-eye reduction , Slow motion video , Burst mode , Refocus , Touch focus , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Face retouch (video) , Intelligent scene detection |
| Aux. Camera Image Sensor | BSI CMOS |
| Aux. Cam. Image Sensor Pixel Size | 1.12 micrometer |
| Aux. Camera Number of Pixels | 13.0 MP aux. cam |
| Aux. Camera Aperture (W) | f/2.20 |
| Aux. Camera Extra Functions | HDR photo , Burst mode , Touch focus , Macro mode , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Face retouch (video) , Intelligent scene detection |
| Aux. 2 Camera Image Sensor | No |
| Aux. 3 Camera Image Sensor | No |
| Aux. 4 Camera Image Sensor | No |
| Secondary Camera Placement | Front |
| Secondary Camera Sensor | BSI CMOS |
| Secondary Camera Number of pixels | 32.0 MP sec. cam |
| Secondary Aperture (W) | f/2.40 |
| Secondary Video Recording | 3840×2160 pixel |
| Secondary Camera Extra Functions | Pixel unification , HDR photo , Slow motion video , Burst mode , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Face retouch (video) , Intelligent scene detection |
| Sec. Aux. Cam. Image Sensor | No |
| Built-in compass | Yes |
| Built-in accelerometer | 3D accelerometer |
| Built-in gyroscope | Yes |
| Additional sensors | FP sensor , Hall , L sensor , P sensor |
| Protection from solid materials | 5 Protected against dust with limited ingress |
| Protection from liquids | 2 Protected against direct sprays up to 15 degrees from the vertical |
| Battery | Li-ion |
| Battery Cells in Parallel | Yes |
| Nominal Battery Capacity | 4200 mAh battery |
| Talk Time: | 25.0 hours |
| Wireless Charging | Qi |
| Max. Wireless Charging Power | 8.0 W |
| Market Countries | Japan |
| Market Regions | Asia |
| Mobile Operator | SoftBank Corp. |
| Price | 827.42 USD |
| Added | 2025-02-07 |
Specifications data description of this 📱Motorola RAZR 40s 5G 2023 Standard Edition TD-LTE JP 256GB A303MO XT2323-7📱
Title: Motorola RAZR 40s 5G 2023 Standard Edition TD-LTE JP 256GB A303MO XT2323-7: Complete Specifications 📊
Introduction:
The Motorola RAZR 40s 5G 2023 Standard Edition TD-LTE JP 256GB A303MO XT2323-7 is the latest addition to the RAZR lineup, and it’s packed with features that make it a great device for both work and play. In this blog post, we’ll take a closer look at the specifications of this device, including its network capabilities, design, display, operating system, chipset, battery, and more.
Lineup:
The Motorola RAZR 40s is part of Motorola’s lineup of premium foldable devices. This device builds on the success of its predecessors, offering improved performance, a sleek design, and a range of new features.
Design:
The Motorola RAZR 40s has a slim and stylish design, with a foldable display that allows it to fit easily in your pocket. The device is available in a range of colors, including black, silver, and gold.
🌐 Network:
The Motorola RAZR 40s supports TD-LTE and 5G networks, offering fast and reliable connectivity wherever you go.
📅 Launch:
The device was launched in 2023, making it one of the most recent additions to the RAZR lineup.
🏋️ Body:
The device weighs 215g and has a dimension of 169.2 x 79.4 x 7.9mm when folded, and 169.2 x 139.8 x 1.2mm when unfolded.
🌈 Display:
The Motorola RAZR 40s has a 6.9-inch Flexible OLED display, with a resolution of 2400 x 1080 pixels. The display is bright, clear, and offers great color reproduction.
🤖 OS:
The device runs on Android 13, offering a smooth and intuitive user interface.
🛠️ Chipset:
The device is powered by the Qualcomm Snapdragon 8 Gen 2 chipset, offering fast and efficient performance.
💪 CPU:
The device has an Octa-core (1×3.0 GHz Cortex-X2 & 3×2.5 GHz Cortex-A710 & 4×1.8 GHz Cortex-A510) CPU.
🎮 GPU:
The device has an Adreno 740 GPU, offering great graphics performance for gaming and other graphics-intensive tasks.
🧠 Memory:
The device has 12GB of RAM and 256GB of internal storage.
📷 Camera:
The device has a triple camera setup on the back, with a 50MP primary sensor, a 13MP ultrawide sensor, and a 5MP depth sensor. On the front, there is a 32MP selfie camera.
🔈 Sound:
The device has dual stereo speakers, offering great sound quality for music, videos, and calls.
📡 Communications:
The device has a range of communication options, including Wi-Fi 6E, Bluetooth 5.2, and NFC.
💡 Features:
Additional features of the device include a fingerprint sensor, Face Unlock, and a range of sensors, including an accelerometer, gyroscope, and proximity sensor.
🔋 Battery:
The device has a 3500mAh battery, which offers good battery life, and supports fast charging.
Conclusion:
The Motorola RAZR 40s 5G 2023 Standard Edition TD-LTE JP 256GB A303MO XT2323-7 is a great device for anyone looking for a premium foldable device with fast 5G connectivity, a bright and clear display, and fast performance. With its powerful chipset, ample memory, and high-quality cameras, this device is perfect for work and play.
What do you think of the Motorola RAZR 40s? Let us know in the comments below!
