Brand | ZTE |
Model | Nubia Red Magic 7 Pro 5G Top Edition Dual SIM TD-LTE CN 512GB NX709J |
Released | 2022 Mar |
Announced | 2022 Feb 17 |
Hardware Designer | ZTE |
Manufacturer | ZTE |
Codename | ZTE 709J |
General Extras | Haptic touch feedback , Tactile touch feedback |
Device Category | Smartphone |
Width | 77.1 mm |
Height | 166.27 mm |
Depth | 9.98 mm |
Dimensions | 3.04×6.55×0.39 inches |
Mass | 235 g |
Platform | Android |
Operating System | Google Android 12 (S) |
Software Extras | Voice Command , Navigation software , Virtual Reality (VR) support , Intelligent personal assistant , Face Recognition |
CPU Clock | 2995 MHz |
CPU | Qualcomm Snapdragon 8 Gen 1 5G SM8450 (Waipio), 2021, 64 bit, octa-core, 6144 Kbyte L3, 4 nm, Qualcomm Adreno 730 GPU |
RAM Type | LPDDR5 SDRAM |
RAM Capacity (converted) | 18 GiB RAM |
Non-volatile Memory Interface | UFS 3.1 |
Non-volatile Memory Capacity (converted) | 512 GB ROM |
Display Diagonal | 172.72 mm |
Resolution | 1080×2400 |
Horizontal Full Bezel Width | 6.22 mm |
Display Area Utilization | 87.1% |
Pixel Density | 387 PPI |
Display Type | AM-OLED display |
Number of Display Scales | 16.8M |
Display Refresh Rate | 120 Hz |
Scratch Resistant Screen | Gorilla Glass 5 |
Graphical Controller | Qualcomm Adreno 730 |
GPU Clock: | 818 MHz |
A/V Out | HDMI |
Microphone(s) | 3 |
Loudspeaker(s): | stereo |
Audio Output: | 3.5mm |
Supported Cellular Bands | GSM850 , GSM900 , GSM1800 , GSM1900 , UMTS2100 (B1) , UMTS1900 (B2) , UMTS1700/2100 (B4) , UMTS850 (B5) , UMTS900 (B8) , UMTS800 (B19) , CDMA800 (BC0) , CDMA1900 (BC1/BC14) , LTE2100 (B1) , LTE1900 (B2) , LTE1800 (B3) , LTE1700/2100 (B4) , LTE850 (B5) , LTE2600 (B7) , LTE900 (B8) , LTE700 (B12) , LTE700 (B17) , LTE800 (B18) , LTE800 (B19) , LTE800 (B20) , LTE850 (B26) , LTE700 (B28) , TD-LTE2000 (B34) , TD-LTE2600 (B38) , TD-LTE2300 (B40) , TD-LTE2500 (B41) , LTE1700/2100 (B66) , NR2100 (N1) , NR1800 (N3) , NR850 (N5) , NR2600 (N7) , NR900 (N8) , NR800 (N20) , NR700 (N28) , TD-NR2600 (N38) , TD-NR2500 (N41) , TD-NR3700 (N77) , TD-NR3500 (N78) bands |
Supported Cellular Data Links | GPRS , EDGE , UMTS , HSUPA , HSUPA 5.8 , HSDPA , HSPA+ 21.1 , DC-HSDPA 42.2 , cdmaOne , CDMA2000 1x , CDMA2000 1xEV-DO , CDMA2000 1xEV-DO Rev A , LTE , LTE 100/50 , LTE 150/50 , LTE 300/50 , LTE 300/75 , LTE 300/100 , LTE 450/50 , LTE 450/100 , LTE 600/50 , LTE 600/100 , LTE 1000/100 , NR 1500 , NR 2600 , NR 3700 data links |
SIM Card Slot | Nano-SIM (4FF) |
Complementary Phone Services | Voice transmission , Voice speaker , Vibrate , Speakerphone , ANC , HD Voice , VoLTE |
Dual Cellular Network Operation | Dual standby |
Sec. Supported Cellular Networks: | GSM850 , GSM900 , GSM1800 , GSM1900 , UMTS2100 (B1) , UMTS1900 (B2) , UMTS1700/2100 (B4) , UMTS850 (B5) , UMTS900 (B8) , UMTS800 (B19) , CDMA800 (BC0) , CDMA1900 (BC1/BC14) , LTE2100 (B1) , LTE1900 (B2) , LTE1800 (B3) , LTE1700/2100 (B4) , LTE850 (B5) , LTE2600 (B7) , LTE900 (B8) , LTE700 (B12) , LTE700 (B17) , LTE800 (B18) , LTE800 (B19) , LTE800 (B20) , LTE850 (B26) , LTE700 (B28) , TD-LTE2000 (B34) , TD-LTE2600 (B38) , TD-LTE2300 (B40) , TD-LTE2500 (B41) , LTE1700/2100 (B66) , NR2100 (N1) , NR1800 (N3) , NR850 (N5) , NR2600 (N7) , NR900 (N8) , NR800 (N20) , NR700 (N28) , TD-NR2600 (N38) , TD-NR2500 (N41) , TD-NR3700 (N77) , TD-NR3500 (N78) |
Sec. Supported Cellular Data Links: | GPRS , EDGE , UMTS , HSUPA , HSUPA 5.8 , HSDPA , HSPA+ 21.1 , DC-HSDPA 42.2 , cdmaOne , CDMA2000 1x , CDMA2000 1xEV-DO , LTE , LTE 100/50 , LTE 150/50 , LTE 300/50 , LTE 300/75 , LTE 300/100 , LTE 450/50 , LTE 450/100 , LTE 600/50 , LTE 600/100 , LTE 1000/100 , NR 1500 , NR 2600 , NR 3700 |
Sec. SIM Card Slot | Nano-SIM (4FF) |
Touchscreen Type | Capacitive multi-touch screen |
Touch Surface Type | Capacitive surface |
Expansion Interfaces | No |
USB | USB 3.0 / 3.1 Gen 1 / 3.2 Gen 1×1 |
USB Services | USB charging , USB fast charging , USB Host , USB OTG 1.3 , USB OTG 2.0 , USB PD , USB PD 2.0 , USB PD 3.0 |
USB Connector | USB C reversible |
Max. Charging Power | 135.0 W |
Bluetooth | Bluetooth 5.2 |
Wireless LAN | 802.11b , 802.11g , 802.11n , 802.11ac , 802.11ax |
Wireless Services | Miracast , Wi-Fi Direct , Wi-Fi Tethering , WiDi , Wi-Fi Calling |
FM Radio Receiver | No |
Complementary Satellite Services | Simultaneous GPS , A-GPS , Dual-frequency GPS , Geotagging , QuickGPS |
Supported GLONASS protocol(s) | L1OF |
Supported BeiDou system (BDS) | B1I BeiDou receiver |
Camera Placement | Rear |
Camera Image Sensor | BSI CMOS |
Image Sensor Pixel Size | 0.70 micrometer |
Number of effective pixels | 64.4 MP camera |
Aperture (W) | f/1.79 |
Zoom | 1.0 x optical zoom |
Focus | PD AF |
Min. Equiv. Focal Length | 26 mm |
Video Recording | 7680×4320 pixel |
Flash | single LED |
Camera Extra Functions | EIS , EIS (video) , Pixel unification , HDR photo , HDR video , Red-eye reduction , Slow motion video , Burst mode , Refocus , Touch focus , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Intelligent scene detection |
Aux. Camera Image Sensor | BSI CMOS |
Aux. Cam. Image Sensor Pixel Size | 1.12 micrometer |
Aux. Camera Number of Pixels | 8.0 MP aux. cam |
Aux. Camera Aperture (W) | f/2.20 |
Aux. Camera Extra Functions | HDR photo , Burst mode , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch |
Aux. 2 Camera Image Sensor | CMOS |
Aux. 2 Camera Number of Pixels | 1.9 MP aux. 2 cam |
Aux. 2 Camera Aperture (W) | f/2.40 |
Aux. 3 Camera Image Sensor | No |
Aux. 4 Camera Image Sensor | No |
Secondary Camera Placement | Under display |
Secondary Camera Sensor | BSI CMOS |
Secondary Camera Number of pixels | 15.9 MP sec. cam |
Secondary Aperture (W) | f/2.00 |
Secondary Video Recording | 7680×4320 pixel |
Secondary Camera Extra Functions | EIS (video) , HDR photo , HDR video , Burst mode , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Intelligent scene detection |
Sec. Aux. Cam. Image Sensor | No |
Built-in compass | Yes |
Built-in accelerometer | 3D accelerometer |
Built-in gyroscope | 3D gyro |
Additional sensors | In-screen FP sensor , HR sensor , L sensor , P sensor |
Protection from solid materials | Yes |
Protection from liquids | Yes |
Battery | Li-ion polymer (LiPo) |
Battery Cells in Parallel | Yes |
Nominal Battery Voltage | 3.87 Volts |
Nominal Battery Capacity | 5000 mAh battery |
Nominal Battery Energy | 19.35 Wh |
Market Countries | China |
Market Regions | Asia |
Price | 6499 CNY |
Added | 2024-06-10 |
